SS 104 A130-130短插頭連接器Fischer
發布時間：2024-11-22 09:20:10 瀏覽：716
SS 104 A130-130是Fischer
Connectors公司生產的一款高性能連接器，屬于其Core系列中的104尺寸產品。這款連接器設計用于低電壓信號或電源的傳輸，具有14個接觸點，采用焊接方式進行端接，推拉式鎖定系統便于連接和斷開，且為線纜安裝類型，適合需要頻繁插拔的場合。外殼由黃銅制成，表面處理為灰色啞光，絕緣材料為高性能的PEEK，確保了產品的耐用性和可靠性。
產品名稱: SS 104 A130-130
系列: SS - SHORT PLUG(短插針)
接觸點數量: 14個
連接器類型: 插頭(Plug)
端接類型: 焊接(Solder)
鎖定系統: 推拉式(Push-pull)
安裝類型: 線纜安裝(Cable Mounted)
信號/電源: 低電壓(Low Voltage)
外殼材料: 黃銅(Brass)
外殼顏色: 灰色啞光(Grey Mat)
絕緣材料: PEEK(聚醚醚酮)
相關型號參數：
| Connector | Contacts | Termination type | Locking system | Signal / Power | Sealing level |
| SS 104 A130-130 | 14 | Solder | Push-pull |
| IP50 |
| 143227 | Low Voltage |
| SS 104 A131-130 | 12 | Solder | Push-pull | Low Voltage | IP50 |
| 143222 |
| SS 1031 A015-130 | 15 | Solder | Push-pull | LowVoltage | IP50 |
| 142813 |
| SS 103 A015-600-C42488 | 1 | Solder | Push-pull | Triax | IP50 |
| 142499 |
| SS 103 A058-150 | 8 | Crimp | Push-pull | LowVoltage | IP50 |
|
| 138771 |
| AL1731-SS-105-A102CP11-13 | 27 | Crimp | Push-pull | Low Voltage | IP50 |
| 136564 |
| AL1731-SS-104-A040CP11-13 | 3 | Crimp | Push-pull | Low Voltage | IP50 |
| 135658 |
| SS 105 Z067-130 | 8 | Solder | Push-pull | Low Voltage | IP50 |
| 135558 |
| SS 103 Z058-150 | 8 | Crimp | Push-pul | Low Voltage | IP50 |
| 135260 |
| AL1731-SS-103-A057CP11-13 | 7 | Crimp | Push-pull | LowVoltage | IP50 |
| 138768 |
| SS 103 Z053-130 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 130546 |
| AL1731-SS-103-A062SR11-13 | 12 | Solder | Push-pul | Low Voltage | IP50 |
| 130163 |
| SS 105 Z062-130 | 10 | Solder | Push-pull | Low Voltage | IP50 |
| 129212 |
| SS 105 z052-130 | 3 | Solder | Push-pull | LowVoltage | IP50 |
| 129124 |
| SS 104 Z040-80 | 3 | Solder | Push-pull | LowVoltage | IP50 |
| 127519 |
| SS 104 A104-130 | 12 | Solder | Push-pul | Low Voltage | IP50 |
| 142766 |
| SS 102 Z052-130 | 3 | Solder | Push-pull | Low Voltage | IP50 |
| 108456 |
| AL1731-SS-105-A053SR11-13 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 124174 |
| SS 105 A102-150 | 27 | Crimp | Push-pull | Low Voltage | IP50 |
| 108803 |
| SS 102 Z051-130 | 2 | Solder | Push-pull | LowVoltage | IP50 |
| 108092 |
| SS 104 Z037-130 | 4 | Solder | Push-pul | Low Voltage | IP50 |
| 120223 |
| SS 104 A051-130 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 112949 |
| SS 105 Z054-130 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 128466 |
| SS 103 Z057-130 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 107971 |
| SS 102 Z056-150 | 7 | Crimp | Push-pull | LowVoltage | IP50 |
| 120672 |
| SS 103 A057-130 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 107732 |
| SS 1031 A105-130 | 14 | Solder | Push-pul | Low Voltage | IP50 |
| 143217 |
| SS 104 Z066-130 | 8 | Solder | Push-pull | Low Voltage | IP50 |
| 104014 |
| SS 103 Z058-130 | 8 | Solder | Push-pul | Low Voltage | IP50 |
| 107957 |
| SS 104 Z092-130 | 19 | Solder | Push-pull | Low Voltage | IP50 |
| 118916 |
| SS 104 Z087-80 | 4 | Solder | Push-pul | LowVoltage | IP50 |
| 104009 |
| SS 104 A124-150 | 27 | Crimp | Push-pul | Low Voltage | IP50 |
| 108863 |
| SS 104 Z053-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 104006 |
| SS 103 Z052-130 | 3 | Solder | Push-pul | Low Voltage | IP50 |
| 125924 |
| SS 105 A069-130 | 12 | Solder | Push-pul | Low Voltage | IP50 |
| 121013 |
| SS 103 A058-130 | 8 | Solder | Push-pull | Low Voltage | IP50 |
| 107959 |
| SS 1031Z010-150 | 10 | Crimp | Push-pul | LowVoltage | IP50 |
| 102527 |
| SS 104 A087-80 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 103635 |
| SS 1031 A010-130 | 10 | Solder | Push-pull | Low Voltage | IP50 |
| 102368 |
| SS 1031Z010-130 | 10 | Solder | Push-pul | Low Voltage | IP50 |
| 102537 |
| SS 105 A104-130 | 13 | Solder | Push-pull | Low Voltage | IP50 |
| 131124 |
| AL1731-SS-1031-A019SR11-13 | 19 | Solder | Push-pull | LowVoltage | IP50 |
| 127319 |
| SS 1031 A010-150 | 10 | Crimp | Push-pul | LowVoltage | IP50 |
| 102442 |
| SS 1031 A019-150 | 19 | Crimp | Push-pull | Low Voltage | IP50 |
| 102426 |
| SS 1031Z019-130 | 19 | Solder | Push-pul | Low Voltage | IP50 |
| 107763 |
| AL1731-SS-104-A092SR11-14 | 19 | Solder | Push-pull | Low Voltage | IP50 |
| 133960 |
| SS 104 A054-130 | 7 | Solder | Push-pull | LowVoltage | IP50 |
| 119981 |
| SS 102 A053-150 | 4 | Crimp | Push-pul | LowVoltage | IP50 |
| 100914 |
| SS 102 A051-130 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 114106 |
| SS 102 Z054-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 101220 |
| SS 105 A038-150 | 18 | Crimp | Push-pul | Low Voltage | IP50 |
| 114024 |
| SS 103 Z056-150 | 6 | Crimp | Push-pull | Low Voltage | IP50 |
| 102165 |
| SS 105 A067-130 | 8 | Solder | Push-pull | Low Voltage | IP50 |
| 106528 |
| SS 104 Z056-130 | 11 | Solder | Push-pul | LowVoltage | IP50 |
| 106483 |
| SS 1031 A012-130 | 12 | Solder | Push-pull | Low Voltage | IP50 |
| 102407 |
| SS 102 A056-150 | 7 | Crimp | Push-pul | Low Voltage | IP50 |
| 100982 |
| AL1731-SS-103-Z051SR11-14 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 133958 |
| SS 103 A062-130 | 12 | Solder | Push-pull | LowVoltage | IP50 |
| 101865 |
| SS 104 A037-150 | 4 | Crimp | Push-pul | LowVoltage | IP50 |
| 135261 |
| SS 103 A053-130 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 115152 |
| SS 102 A054-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 100897 |
| SS 105 Z069-130 | 12 | Solder | Push-pul | Low Voltage | IP50 |
| 132302 |
| SS 104 Z055-130 | 9 | Solder | Push-pull | Low Voltage | IP50 |
| 114770 |
| SS 105 A062-130 | 10 | Solder | Push-pull | Low Voltage | IP50 |
| 128346 |
| SS 103 A051-130 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 101877 |
| SS 1031 A012-150 | 12 Crimp | Push-pull | Low Voltage | IP50 |
| 102463 |
| SS 105 A093-80 | 24 | Solder | Push-pull | Low Voltage | IP50 |
| 123972 |
| SS 102 A056-130 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 100888 |
| SS 105 Z093-80 | 24 | Solder | Push-pull | Low Voltage | IP50 |
| 119636 |
| AL1731-SS-103-A054CP11-13 | 5 | Crimp | Push-pull | Low Voltage | IP50 |
| 131226 |
| SS 102 A053-130 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 100901 |
| SS 1031 A019-130 | 19 | Solder | Push-pull | Low Voltage | IP50 |
| 102423 |
| SS 104 A056-130 | 11 | Solder | Push-pull | Low Voltage | IP50 |
| 103563 |
| SS 104 A040-80 | 3 | Solder | Push-pull | Low Voltage | IP50 |
| 125055 |
| SS 103 A054-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 101878 |
| SS 103 Z054-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 102176 |
| SS 104 A092-130 | 19 | Solder | Push-pull | Low Voltage | IP50 |
| 107949 |
| AL1731-SS-102-Z051SR11-13 | 2 | Solder | Push-pull | Low Voltage | IP50 |
| 125995 |
| SS 102 Z053-130 | 4 | Solder | Push-pull | Low Voltage | IP50 |
| 101230 |
| SS 105 Z102-150 | 27 | Crimp | Push-pul | Low Voltage | IP50 |
| 137515 |
| SS 104 Z053-150 | 5 | Crimp | Push-pull | Low Voltage | IP50 |
| 108520 |
| AL1731-SS-102-A054SR11-13 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 121134 |
| SS 103 A052-130 | 3 | Solder | Push-pull | Low Voltage | IP50 |
| 101907 |
| SS 105 A102-130 | 27 | Solder | Push-pull | Low Voltage | IP50 |
| 113051 |
| SS 102 Z056-130 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 113078 |
| AL1731-SS-102-A056SR11-13 | 7 | Solder | Push-pull | Low Voltage | IP50 |
| 113189 |
| SS 105 Z110-130 | 16 | Solder | Push-pull | Low Voltage | IP50 |
| 129308 |
| SS 103 Z056-130 | 6 | Solder | Push-pull | Low Voltage | IP50 |
| 113991 |
| SS 103 A062-160 | 12 | Crimp | Push-pull | Low Voltage | IP50 |
| 113388 |
| SS 104 A086-130 | 16 | Solder | Push-pull | Low Voltage | IP50 |
| 113409 |
| SS 104 A055-130 | 9 | Solder | Push-pull | Low Voltage | IP50 |
| 114771 |
| SS 102 A066-130 | 2 | Solder | Push-pull | Low Voltage | IP50 |
| 140901 |
| SS 1031Z012-130 | 12 | Solder | Push-pull | Low Voltage | IP50 |
| 113992 |
| SS 102 Z054-150 | 5 | Crimp | Push-pull | Low Voltage | IP50 |
| 114107 |
| AL1231-SS-103-A062CP11-13 | 12 | Crimp | Push-pull | Low Voltage | IP50 |
| 114145 |
| SS 1031Z019-150 | 19 | Crimp | Push-pull | Low Voltage | IP50 |
| 114240 |
| SS 105 Z058-130 | 15 | Solder | Push-pull | Low Voltage | IP50 |
| 127137 |
| AL1731-SS-102-A052SR11-13 | 3 | Solder | Push-pull | Low Voltage | IP50 |
| 114200 |
| SS 103 Z051-130 | 2 | Solder | Push-pull | Low Voltage | IP50 |
| 116260 |
| SS 102 A059-130 | 9 | Solder | Push-pull | Low Voltage | IP50 |
| 114037 |
| SS 102 A054-150 | 5 | Crimp | Push-pull | Low Voltage | IP50 |
| 125382 |
| SS 104 A066-130 | 8 | Solder | Push-pull | Low Voltage | IP50 |
| 103648 |
| SS 104 Z086-130 | 16 | Solder | Push-pull | Low Voltage | IP50 |
| 116384 |
| SS 104 A053-130 | 5 | Solder | Push-pull | Low Voltage | IP50 |
| 116669 |
| SS 105 A058-130 | 15 | Solder | Push-pull | Low Voltage | IP50 |
| 116670 |
| SS 1031 A029-130 | 12 | Solder | Push-pull | Low Voltage | IP50 |
| 142781 |
| SS 102 Z053-150 | 4 | Crimp | Push-pul | Low Voltage | IP50 |
| 101207 |
| SS 104 A037-130 | 4 | Solder | Push-pul | Low Voltage | IP50 |
| 116725 |
| SS 104 A065-130 | 6 | Solder | Push-pul | Low Voltage | IP50 |
| 116964 |
| SS 104 Z065-130 | 6 | Solder | Push-pull | Low Voltage | IP50 |
| 116965 |
| AL1731-SS-103-A053SR11-14 | 4 | Solder | Push-pul | Low Voltage | IP50 |
| 121043 |
| SS 105 A087-130 | 2 | Solder | Push-pull | Low Voltage | IP50 |
| 116999 |
| SS 105 Z087-130 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 117087 |
| SS 104 Z051-130 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 134242 |
| SS 102 Z059-130 | 9 | Solder | Push-pull | Low Voltage | IP50 |
| 118924 |
| AL1731-SS-104-A066CP11-13 | 8 | Crimp | Push-pul | Low Voltage | IP50 |
| 136577 |
| SS 105 Z102-130 | 27 | Solder | Push-pul | Low Voltage | IP50 |
| 119798 |
| SS 105 Z053-130 | 4 | Solder | Push-pul | Low Voltage | IP50 |
| 120071 |
| AL1731-SS-1031-A010SR11-13 | 10 | Solder | Push-pull | Low Voltage | IP50 |
| 126511 |
| AL1731-SS-102-A051SR11-13 | 2 | Solder | Push-pul | Low Voltage | IP50 |
| 121132 |
| SS 102 A051-150 | 2 | Crimp | Push-pul | Low Voltage | IP50 |
| 106286 |
| SS 105 A053-130 | 4 | Solder | Push-pul | Low Voltage | IP50 |
| 120815 |
| SS 103 A056-130 | 6 | Solder | Push-pull | Low Voltage | IP50 |
| 101870 |
| SS 1031 Z012-150 | 12 | Crimp | Push-pul | Low Voltage | IP50 |
| 123957 |
| SS 102 A052-130 | 3 | Solder | Push-pull | Low Voltage | IP50 |
| 100890 |
| AL1731-SS-105-A093SR11-13 | 24 | Solder | Push-pul | Low Voltage | IP50 |
| 124175 |
| AL1731-SS-1031-A012SR11-13 | 12 | Solder | Push-pull | Low Voltage | IP50 |
| 126512 |
| SS 105 A110-130 | 16 | Solder | Push-pull | Low Voltage | IP50 |
| 105020 |
| SS 105 A038-130 | 18 | Solder | Push-pul | LowVoltage | IP50 |
| 125917 |
| SS 105 A124-130 | 8 | Solder | Push-pul | Low Voltage | IP50 |
| 125139 |
| SS 105 A062-150 | 10 | Crimp | Push-pul | Low Voltage | IP50 |
| 126184 |
